Lockheed Martin Offers Mk70 Launcher to Increase Lethality of LCS

An SM-6 missile is launched from a containerized launcher on board USS Savannah (LCS 28) on Oct. 24, 2023. (U.S. Navy photo)

By Richard R. Burgess, Senior Editor

ARLINGTON, Va. — Lockheed Martin has adapted its Mk41 vertical missile launcher into a scalable containerized system than can be deployed on U.S. Navy ships, including the littoral combat ships (LCS) and non-traditional platforms of opportunity to increase their lethality with mid-range precision strike and air defense capabilities. company officials said.

The system, called the Mk70 Payload Delivery System, is a 40-foot-long ISO container in which four VLS cells can be fitted. The Mk70 system, designed for and deployed with the U.S. Army in a land-based configuration, can launch any type of missile certified for the Mk41, including the Tomahawk cruise missile, the various Standard surface-to-air missiles, the antisubmarine rocket, and the Evolved SeaSparrow missile. The Mk70 container is transportable on a C-17 cargo aircraft.

Ed Dobeck, director for launching systems at Lockheed Martin, told Seapower that the Mk70 was developed two years ago in concert with the Defense Department’s Strategic Capabilities Office to provide the Army with the ability to deploy and fire the Raytheon-built SM-6 Standard missile.

The same container can be secured on the flight deck or helicopter landing pad of a Navy ship using helicopter tie-down chains, occupying 400 square feet of a flight deck. Power from the ship’s electrical system can supply 400 volts to the Mk70. No modifications are required to the ship itself. The container can be installed within hours with a pier-side crane. A command shelter with virtual Aegis and Tomahawk control systems controls the launch of the missiles.

The flight deck of the Freedom-class LCS can accommodate three Mk70 containers, while the Independence-class LCS can accommodate four containers, Dobeck said. With one or more containers installed, the ships are unable to launch or land helicopters. The missile tubes can be reloaded horizontally, an advantage over the ship-installed Mk41’s need for vertical re-load by cranes.

Lockheed Martin has demonstrated containerized launch of SM-6 missiles from two Navy ships. An SM-6 missile was fired from the USS Savannah (LCS 28) in October 2023 and before that another was fired from the Overlord medium unmanned surface vessel Ranger during an exercise.

Dobeck said that the Navy has shown great interest in the Mk70 system, which already has been delivered to the Army. Two full batteries — totaling eight missile cells — have been delivered to the Army and two have been delivered to other customers. The Army has deployed the Mk70 to the Philippines
